Use Netty to proxy your requests

User Rating: 4 / 5

Star ActiveStar ActiveStar ActiveStar ActiveStar Inactive


Are you looking for a proxy to debug your client-server communication ? look no further! Netty has ready to run examples to do the job for you!

Netty is a NIO client server framework which enables quick and easy development of network applications such as protocol servers and clients. It greatly simplifies and streamlines network programming such as TCP/IP socket server. You can find here a startup tutorial about Netty.

In Netty, the main injection point into your code or business logic is achieved by means of handlers.  Handlers are based on the interceptor pattern just like filters do in a traditional servlet-based web application.  Handlers provide an event model that allows an application to monitor incoming/outgoing data, modify the data, convert the data, act upon the data, etc.  In short, handlers allow you to completely abstract separate concerns into separate classes.

Handlers are added to the pipeline using a specific order.  The order determines how and when the handlers are invoked.  So if one handler depends on another handler (a compression handler for example) then, you need to make sure that the codec handler comes before in the pipeline.  As data enters the system, often times asynchronously, the data is wrapped in a channel buffer object.  The object is then flowed from the first handler downstream to the last handler (unless a handler chooses to break the flow or an exception is thrown).



 Here's a diagram taken from the Netty documentation:


In the following example, we will show how to proxy requests between a client and a server using the HexDumpProxy which is part of Netty examples. Here's the main class:

package org.jboss.netty.example.proxy;

import java.net.InetSocketAddress;
import java.util.concurrent.Executor;
import java.util.concurrent.Executors;

import org.jboss.netty.bootstrap.ServerBootstrap;
import org.jboss.netty.channel.socket.ClientSocketChannelFactory;
import org.jboss.netty.channel.socket.nio.NioClientSocketChannelFactory;
import org.jboss.netty.channel.socket.nio.NioServerSocketChannelFactory;

public class HexDumpProxy {

    public static void main(String[] args) throws Exception {
        // Validate command line options.
        if (args.length != 3) {
            System.err.println(
                    "Usage: " + HexDumpProxy.class.getSimpleName() +
                    " <local port> <remote host> <remote port>");
            return;
        }

        // Parse command line options.
        int localPort = Integer.parseInt(args[0]);
        String remoteHost = args[1];
        int remotePort = Integer.parseInt(args[2]);


        System.err.println(
                "Proxying *:" + localPort + " to " +
                remoteHost + ':' + remotePort + " ...");

        // Configure the bootstrap.
        Executor executor = Executors.newCachedThreadPool();
        ServerBootstrap sb = new ServerBootstrap(
                new NioServerSocketChannelFactory(executor, executor));

        // Set up the event pipeline factory.
        ClientSocketChannelFactory cf =
                new NioClientSocketChannelFactory(executor, executor);

        sb.setPipelineFactory(
                new HexDumpProxyPipelineFactory(cf, remoteHost, remotePort));

        // Start up the server.
        sb.bind(new InetSocketAddress(localPort));
    }
}

As you can see, this class does barely three things:

  • Bootstrap a Server
  • Creates a custom Socket Pipeline (HexDumpProxyPipeline) from the ClientSocketChannelFactory and assign it to the server
  • Bind the server to an IP Address

Here's the HexDumpProxyPipelineFactory which register itself at the end of the Channel Pipeline

package org.jboss.netty.example.proxy;

import static org.jboss.netty.channel.Channels.*;

import org.jboss.netty.channel.ChannelPipeline;
import org.jboss.netty.channel.ChannelPipelineFactory;
import org.jboss.netty.channel.socket.ClientSocketChannelFactory;


public class HexDumpProxyPipelineFactory implements ChannelPipelineFactory {

    private final ClientSocketChannelFactory cf;
    private final String remoteHost;
    private final int remotePort;

    public HexDumpProxyPipelineFactory(
            ClientSocketChannelFactory cf, String remoteHost, int remotePort) {
        this.cf = cf;
        this.remoteHost = remoteHost;
        this.remotePort = remotePort;
    }

    public ChannelPipeline getPipeline() throws Exception {
        ChannelPipeline p = pipeline(); // Note the static import.
        p.addLast("handler", new HexDumpProxyInboundHandler(cf, remoteHost, remotePort));
        return p;
    }
}

And here's the handler which manages the Channels and contains the logic to print the Hex of the data which is proxied.
package org.jboss.netty.example.proxy;

import java.net.InetSocketAddress;

import org.jboss.netty.bootstrap.ClientBootstrap;
import org.jboss.netty.buffer.*;
import org.jboss.netty.channel.*;

import org.jboss.netty.channel.SimpleChannelUpstreamHandler;
import org.jboss.netty.channel.socket.ClientSocketChannelFactory;


public class HexDumpProxyInboundHandler extends SimpleChannelUpstreamHandler {

    private final ClientSocketChannelFactory cf;
    private final String remoteHost;
    private final int remotePort;

    private volatile Channel outboundChannel;

    public HexDumpProxyInboundHandler(
            ClientSocketChannelFactory cf, String remoteHost, int remotePort) {
        this.cf = cf;
        this.remoteHost = remoteHost;
        this.remotePort = remotePort;
    }

    @Override
    public void channelOpen(ChannelHandlerContext ctx, ChannelStateEvent e)
            throws Exception {
        // Suspend incoming traffic until connected to the remote host.
        final Channel inboundChannel = e.getChannel();
        inboundChannel.setReadable(false);

        // Start the connection attempt.
        ClientBootstrap cb = new ClientBootstrap(cf);
        cb.getPipeline().addLast("handler", new OutboundHandler(e.getChannel()));
        ChannelFuture f = cb.connect(new InetSocketAddress(remoteHost, remotePort));

        outboundChannel = f.getChannel();
        f.addListener(new ChannelFutureListener() {
            public void operationComplete(ChannelFuture future) throws Exception {
                if (future.isSuccess()) {
                    // Connection attempt succeeded:
                    // Begin to accept incoming traffic.
                    inboundChannel.setReadable(true);
                } else {
                    // Close the connection if the connection attempt has failed.
                    inboundChannel.close();
                }
            }
        });
    }

    @Override
    public void messageReceived(ChannelHandlerContext ctx, MessageEvent e)
            throws Exception {
        ChannelBuffer msg = (ChannelBuffer) e.getMessage();
        System.out.println(">>> " + ChannelBuffers.hexDump(msg));
        outboundChannel.write(msg);
    }

    @Override
    public void channelClosed(ChannelHandlerContext ctx, ChannelStateEvent e)
            throws Exception {
        if (outboundChannel != null) {
            closeOnFlush(outboundChannel);
        }
    }

    @Override
    public void exceptionCaught(ChannelHandlerContext ctx, ExceptionEvent e)
            throws Exception {
        e.getCause().printStackTrace();
        closeOnFlush(e.getChannel());
    }

    private static class OutboundHandler extends SimpleChannelUpstreamHandler {

        private final Channel inboundChannel;

        OutboundHandler(Channel inboundChannel) {
            this.inboundChannel = inboundChannel;
        }

        @Override
        public void messageReceived(ChannelHandlerContext ctx, MessageEvent e)
                throws Exception {
            ChannelBuffer msg = (ChannelBuffer) e.getMessage();
            System.out.println("<<< " + ChannelBuffers.hexDump(msg));
            inboundChannel.write(msg);
        }

        @Override
        public void channelClosed(ChannelHandlerContext ctx, ChannelStateEvent e)
                throws Exception {
            closeOnFlush(inboundChannel);
        }

        @Override
        public void exceptionCaught(ChannelHandlerContext ctx, ExceptionEvent e)
                throws Exception {
            e.getCause().printStackTrace();
            closeOnFlush(e.getChannel());
        }
    }

    /**
     * Closes the specified channel after all queued write requests are flushed.
     */
    static void closeOnFlush(Channel ch) {
        if (ch.isConnected()) {
            ch.write(ChannelBuffers.EMPTY_BUFFER).addListener(ChannelFutureListener.CLOSE);
        }
    }
}
